Feature code port and cable support: All the IVE feature codes have different connectivity options and different cable support.
FC 5636 and FC 5639 support: � 1 Gbps connectivity � 10 Mbps and 100 Mbps connectivity � RJ-45 connector
Use the Ethernet cables that meet Cat 5e3 cabling standards, or higher, for best performance.
FC 5637 supports: � 10 Gbps SR connectivity � 62.5 micron multi-mode fiber cable type – LC optical physical connector type – 33 meters maximum range
Source: redp-4340-00 Integrated Virtual Ethernet Adapter - Technical Overview and Introduction.
